EPA Method 6: Determination of Sulfur Dioxide Emissions from Stationary Sources

ESC M6-S1 Method 6 Sampling Train

An efficient low flow, non-isokinetic system for extracting a gas sample from the stack and separating the sulfuric acid mist, including sulfur trioxide, from the sulfur dioxide fraction that is to be measured using barium-thorin tritration. This train is outfitted with a minature, pyrex lined, heated probe assembly, a midget sample caddy with insulated glassware tray, a midget glassware set, the impinger outlet adapter with thermocouple and the UC-25U umbilical with connector box.

The UNI-VOS-ACD Low Flow Control Console is the preferred console for use with this train (not included with the M6-S1).

Included in M6-S1:

• Qty 1 M6-SC Method 6/26 Sample Caddy with Probe Support
• Qty 1 PRSM-S03 3ft Heated Miniature Probe Assembly
• Qty 3 PRLM-P03-06 3ft Pyrex Liner, 3/8” with Cup, 5/8”
• Qty 1 PRMM-035-3/8 3ft x 3/8" Diameter Miniature Heater
• Qty 1 PFA-SU6 3/8” PFA Teflon Union
• Qty 1 M6-PPL Handheld Probe Purge Bulb
• Qty 1 M6-CB Insulated SS Glassware Tray
• Qty 1 GSM-6B Midget Method 6 Glassware Set, Ball Jt with O–Ring
• Qty 1 UA-12 SS 1/25 Umbilical Adapter, TC, Jumpline
• Qty 1 UC-LF-025 25ft Low Flow Umbilical Cable
• Qty 1 JB-15 Junction Box with 4-Pin Receptacle

The standard GSM-6B Midget Glassware Set is precision ground ball and socket joint with O-ring for leak-free performance. The stem-to-bottle taper joint is also a precision ground joint with O-ring seal. This set includes specifically:

• Qty 1 GP-606 3-Way Pyrex Valve with Teflon Plunger
• Qty 4 GP-607 Midget Impinger
• Qty 1 GP-608 Midget Impinger with Orifice
• Qty 4 GP-609 Midget U-Tube Connector
• Qty 12 GP-611 Stainless Steel Pinch Clamp, #12
